Advanced Thermal Efficiency
Store & Storage Solutions
Maximize energy ROI with our high-performance thermal store tanks and chilled water systems. Engineered for data centers and district cooling, featuring precision-designed diffusers for superior stratification.
The Science of Stratification
Our stratified thermal storage systems maintain an ultra-sharp thermocline, ensuring maximum usable energy capacity and system efficiency.
Thermocline Management
Efficiency in a Chilled Water Thermal Storage Tank relies on preventing the mixing of return water and stored water. Our precision-engineered octagonal diffusers utilize buoyancy to create stable, horizontal flow layers.
Reduces velocity to prevent turbulence and mixing at the interface.
Optimized geometry for uniform water distribution across the tank width.
Over 95% storage efficiency by minimizing the thermocline thickness.
Ensures equal flow paths for consistent temperature output.
Core Thermal Product Lines
Our engineering team specializes in two distinct thermal disciplines, providing custom-built storage for both peak-shaving cooling and waste heat recovery.
Chilled Water Thermal Storage
- Emergency cooling for Data Centers during power outages.
- Peak-load shifting to reduce utility costs (off-peak ice/water storage).
- Precision radial diffusers for stable thermocline management.
Thermal Store & Buffer Tanks
- Heat recovery systems for industrial process loops.
- Biomass boiler buffering and solar thermal integration.
- Multi-port header designs for complex hydraulic integration.
Engineering Specifications
Our stratified tanks are manufactured to international pressure vessel standards, ensuring long-term durability and thermal performance in demanding industrial environments.
| Technical Parameter | Chilled Water Storage Tank | Hot Water / Thermal Store |
|---|---|---|
| Capacity Range | 1,000L to 150,000L+ | 500L to 120,000L |
| Design Pressure | Standard 6 / 10 / 16 Bar (Custom available) | Standard 6 / 10 Bar |
| Shell Material | Q235B Carbon Steel / 304 Stainless Steel | Q345R Pressure Vessel Steel / 316 Stainless |
| Internal Coating | Food-Grade Epoxy (Water Safe) | Phenolic Resin / Passivated Stainless Steel |
| Insulation Material | High-Density Polyurethane Foam (PUF) | Fire-Resistant Rockwool / Fiber Glass |
| External Jacketing | Aluminum / Color-Coated Steel Plate | Weather-Proof Galvanized / SS 304 Jacket |
| Stratification Device | Octagonal Radial Diffusers | Multi-Port Siphon / Header Pipes |
| Compliance | ASME VIII GB/T 150 CE/PED | ASME VIII ISO 9001 |
Applications & Case Studies
Our advanced thermal storage solutions are deployed across diverse industries, delivering robust energy management and operational resilience.
Data Centers & IT Infrastructure
Ensuring 24/7 cooling is critical for data centers. Our chilled water tanks provide a reliable emergency cooling source and enable off-peak energy use for cost savings.
- Reduced PUE (Power Usage Effectiveness)
- Critical cooling redundancy
- Lower operational cooling costs
District Cooling & Heating Networks
Integrating large-scale thermal storage into district energy systems balances supply and demand, optimizes chiller/boiler operation, and reduces grid strain.
- Peak load shifting & energy arbitrage
- Enhanced grid stability
- Reduced carbon footprint
Industrial Process Cooling & Heating
Manufacturing and processing plants benefit from thermal buffer tanks to manage fluctuating loads, recover waste heat, and provide stable process temperatures.
- Stable process temperature control
- Waste heat recovery efficiency
- Reduced energy consumption
Industrial Reliability & Compliance
Our thermal storage systems are built to endure, ensuring maximum energy density and zero-leak reliability under industrial pressures.
100% Weld Inspection
Advanced NDT (X-ray and Ultrasonic) testing ensures every structural joint meets high-pressure safety codes.
Hydrostatic Proof
Every tank is water-tested at 150% of its rated design pressure before receiving its certification stamp.
Infrared Heat-Loss Audit
Pre-shipment thermographic scanning validates that insulation performance meets the 98% efficiency threshold.
Full Traceability
Comprehensive steel mill records and batch tracking for every component, compliant with ISO and ASME protocols.
Engineering Support & FAQ
What is the typical standing heat loss rate?
How does the internal diffuser impact efficiency?
Recommendations for installation space and footprint?
Optimize Your System's Efficiency
Not sure which configuration fits your load profile? Consult our senior engineers for a comprehensive efficiency audit and tailored selection report for your project.
Book an Efficiency Audit
